snowsk8air2 how hard can it be?

Joined:

Sep 16, 2011

Member:

#63607

Messages:

8,800

Gender:

Male

First Name:

Ryan

Flagstaff, AZ

Vehicle:

Supercharged TX Pro

2011 S/C and basic mods

See my prob with the d60 option is you can't get it in 5.29 which is what I plan to jump to for 37's. That and I'm sua and would have to cut off the spring perches and shock mounts anyways. And would want wider to match my LT front and eliminate the need for wheel spacers. And by the time you build it up with gearing and a locker it's not much cheaper than a custom 9" from Currie. That said if your gearing option is available and you still have stock suspension configuration it does seem like a great option.
I guess I could see in an MT but if you are AT then 5.29 seem too tall for 37s. However, I understand it is greatly dependent on where you live, how you use your truck, towing and personal preference.
sawjai526 Well-Known Member

Joined:

Jun 20, 2013

Member:

#106644

Messages:

280

Gender:

Male

First Name:

vincent

Bayarea, CA

Vehicle:

15 DCSB OR 6spd

thanks, going to try it out now
Using a plastic trim tool as opposed to thumb nail may help...any body got a part number for that piece by chance??
White lightning boosted Well-Known Member

Joined:

Dec 30, 2017

Member:

#239848

Messages:

7,229

Gender:

Male

First Name:

Jesse

Poulsbo

Vehicle:

15' DCSB OR S/C

Lift, pedal commander, led foglights, led interior lights, led back ups, led under lighting, urd tcai, led headlights, methanol injection, 76mm tb, hood struts, dif breather mod, ratiotek trans kit, x-series gauges, true cool trans cooler, belt wrap mod, 2.8 pulley

Countersteer type x think they're only 21 lbs
snowsk8air2 how hard can it be?

Joined:

Sep 16, 2011

Member:

#63607

Messages:

8,800

Gender:

Male

First Name:

Ryan

Flagstaff, AZ

Vehicle:

Supercharged TX Pro

2011 S/C and basic mods

Well with the AT the correct ratio to get back to stock is closer to 5.13, but that's not an option either with the d60 and I don't believe it is an option for the front diff either. I'm 4.56 with 35's and already wish I had 4.88 so I can only imagine when I go to 37's I'll certainly want more than 4.88. My worry is going that tall of gearing with the stock axle. I'm afraid I'll just start breaking stuff. I've been told the 5.7 tundra axle will fit under our trucks and maintain wheel speed sensors and abs stuff plus be wider to match up with front LT, which would be the cheapest option to find from a junkyard. But again the highest gearing they offer is 4.88 for those. We'll see how much I hate the 4.56 when I jump to 37's and see if the tundra axle is a viable option or if I'll have to pony up the big bucks on something custom.
mr.trd Are you Recreationally Insane?

Joined:

Jul 9, 2008

Member:

#7842

Messages:

1,444

Gender:

Male

First Name:

Brant

Pocatello, Idaho

Vehicle:

'06 S/C 1GR-FE DCSB

Icon coilovers w 14" 700lb springs, Icon billet UCA w/ Delta joints, custom built Icon rear resi-shocks, Icon stage 3 rear leaf pack, Archive Garage Hammer Hangers w/ homemade spreader bar, superbumps up front and timbren bumps in the rear, Crown brake lines, U-bolt flip,4.88's with front ARB locker and ARB dual compressor mounted behind back seat, 285/75R17 BFG A/T KO2's on Bronze Icon Alloy Compression's, 5th gen T4R budget big brake kit, CBI Off-Road Fab. custom Trailmaster 2.0 with swing-away tire carrier, CBI custom tube front bumper, CBI kickout sliders, CBI full flat belly skids including gas tank,CBI Ditch Light brackets w/ Heretic Studio Quattro's, Heretic Studio's 30" Amber on the front, Heretic Studio 40" bar under the Front Runner Roof Rack, Expedition Essentials RAM mount, Leer used shell, OEM black chrome sport headlights, fog lights always on mod, rear locker anytime mod, TRD supercharger, URD Ucon-EMS, Deatschwerks 255 fuel pump w/ URD external fuel filter kit, AFE intake paired to a Safari Snorkel, URD spec-U exhaust w/ factory Tundra muffler behind URD equal length headers.

Absolutely love those wheels. I just went with the Icon Compression, well because I am an Icon whore, and the only thing I don't like is the weight. Going from 16x8 Konig Countersteer offroads that were 18 lbs with 285/75R16 MT/R's to the 17x8.5 Icon Alloy Compressions that are 28lbs with 285/75R17 KO2's was a noticable difference even with 4.88's. But I did get an extra 300 rpm decrease at highway speeds. So only 2900 rpm at 80mph.
mr.trd Are you Recreationally Insane?

Joined:

Jul 9, 2008

Member:

#7842

Messages:

1,444

Gender:

Male

First Name:

Brant

Pocatello, Idaho

Vehicle:

'06 S/C 1GR-FE DCSB

Icon coilovers w 14" 700lb springs, Icon billet UCA w/ Delta joints, custom built Icon rear resi-shocks, Icon stage 3 rear leaf pack, Archive Garage Hammer Hangers w/ homemade spreader bar, superbumps up front and timbren bumps in the rear, Crown brake lines, U-bolt flip,4.88's with front ARB locker and ARB dual compressor mounted behind back seat, 285/75R17 BFG A/T KO2's on Bronze Icon Alloy Compression's, 5th gen T4R budget big brake kit, CBI Off-Road Fab. custom Trailmaster 2.0 with swing-away tire carrier, CBI custom tube front bumper, CBI kickout sliders, CBI full flat belly skids including gas tank,CBI Ditch Light brackets w/ Heretic Studio Quattro's, Heretic Studio's 30" Amber on the front, Heretic Studio 40" bar under the Front Runner Roof Rack, Expedition Essentials RAM mount, Leer used shell, OEM black chrome sport headlights, fog lights always on mod, rear locker anytime mod, TRD supercharger, URD Ucon-EMS, Deatschwerks 255 fuel pump w/ URD external fuel filter kit, AFE intake paired to a Safari Snorkel, URD spec-U exhaust w/ factory Tundra muffler behind URD equal length headers.

I thought I read somewhere that Nitro now has a 5.29 for the Tundra axle. Quick search says it should be available around April.
snowsk8air2 how hard can it be?

Joined:

Sep 16, 2011

Member:

#63607

Messages:

8,800

Gender:

Male

First Name:

Ryan

Flagstaff, AZ

Vehicle:

Supercharged TX Pro

2011 S/C and basic mods

That could be a deciding factor for me. Next would be to figure out how to swap the tundra front diff in, but that would be a little tougher than rear axle. I'm not jumping to 37's until this fall/ winter so probably wouldn't be regearing again until next spring.
sawjai526 Well-Known Member

Joined:

Jun 20, 2013

Member:

#106644

Messages:

280

Gender:

Male

First Name:

vincent

Bayarea, CA

Vehicle:

15 DCSB OR 6spd

@BassAckwards it worked! used a pick to break the dirt built under cap, then it unscrew counter clockwise as you stated! removed the pulley but got rained on, need to put new one back on when the rain stops. thanks!
snowsk8air2 how hard can it be?

Joined:

Sep 16, 2011

Member:

#63607

Messages:

8,800

Gender:

Male

First Name:

Ryan

Flagstaff, AZ

Vehicle:

Supercharged TX Pro

2011 S/C and basic mods
ThomasMore66 We can't stop here, this is bat country!

Joined:

Feb 9, 2013

Member:

#97155

Messages:

7,276

Gender:

Male

Dallas/Fort Worth & Durango

Vehicle:

Supercharged 2013 TRD Offroad 4wd

TRD Supercharger, TRD exhaust, Leather seats, running boards removed (why it came with them I cannot imagine), Salex organizers, BAMF behind-the-grill light bar, Rigid SR-20 and SR-Q - Spots mounted behind stock grill, color-matched grill, WeatherTech FloorLiner DigitalFit floor mats, Tech Deck, Avid bolt-on slider/step converted to weld on by TW member Achirdo, Diaz Fabrication Model T, Icon Stage 4 with OME Dakar rear leaf springs, OME Driveshaft spacer, Toytec 1" Front Diff Drop, FN BFD 18"x9" GMG Wheels, BFG KO2 285-65-18 tires, Ultragauge mounted above mirror, Tuffy Box lockable storage, MattGecko rear window security bar, Relentless Fab tailgate protector, CSJumper 700 lumen flood pattern back-up LED's, modified BeeRadd under-hood lighting with two KC Cyclones; KB Voodoo cargo management system and standard rails, AllPro hi-lift jack mount, 48" hi-lift, RCI Metalworks aluminum front skid, Flyzeye 3VP-RS in glovebox and console, AFE CAI, Coupe fuse box cover, battery hold-down bracket and CAI air-box cover, Wurton pod led's installed as bed lights on Lowbrow Customs motorcycle fork brake line aluminum brackets, Pop-n-Lock PL5400, Extang Solidfold 2.0, Rechelon Retro's, Moromoto LED fogs, URD Y-pipe, Walbro 255lph fuel pump, Speedhut AFR and Boost gauges, Cravenspeed gauge holder, CMC by Tandem Automotive, 70mm throttle body, CSF radiator, Doug Thorley shorties, Vibrant 7101 cats, SOS Offroad front and rear bumpers, Smoothflow 2.5" SC pulley, Steeda SC belt tensioner, roostfactor belt wrap kit, switch Pro 9100 in custom Tandem Automotive holder, WAT trans valvebody, FIC 650cc injectors, HP Tuner.

You just need more horsepower.
Need suggestions on how to get a TRD SC tune that I never knew I needed.
1. Dealership says they don't have the option on Techstream and can't help.

2. After waiting for what I mistakenly thought was an SC tune file, @OVTune informed I needed a TRD SC tune first. He said he could do it but I would have to unlock some things first and then mail it to him. Not specific on what I need to do and no phone number to ever reach out and too busy with everyone to help individuals. It is my daily so simply mailing away my ECU isn't really an option either.

3. Now what?? Am I just screwed or how did anyone else get a TRD tune? I have the OVTune handheld. Am I just stuck with going the UCON route?

Thanks for any help. Not sure why this is such a mystery after all this time. So frustrating having all this untapped potential sitting in my garage to just stare at.
sawjai526 Well-Known Member

Joined:

Jun 20, 2013

Member:

#106644

Messages:

280

Gender:

Male

First Name:

vincent

Bayarea, CA

Vehicle:

15 DCSB OR 6spd
ThomasMore66 We can't stop here, this is bat country!

Joined:

Feb 9, 2013

Member:

#97155

Messages:

7,276

Gender:

Male

Dallas/Fort Worth & Durango

Vehicle:

Supercharged 2013 TRD Offroad 4wd

TRD Supercharger, TRD exhaust, Leather seats, running boards removed (why it came with them I cannot imagine), Salex organizers, BAMF behind-the-grill light bar, Rigid SR-20 and SR-Q - Spots mounted behind stock grill, color-matched grill, WeatherTech FloorLiner DigitalFit floor mats, Tech Deck, Avid bolt-on slider/step converted to weld on by TW member Achirdo, Diaz Fabrication Model T, Icon Stage 4 with OME Dakar rear leaf springs, OME Driveshaft spacer, Toytec 1" Front Diff Drop, FN BFD 18"x9" GMG Wheels, BFG KO2 285-65-18 tires, Ultragauge mounted above mirror, Tuffy Box lockable storage, MattGecko rear window security bar, Relentless Fab tailgate protector, CSJumper 700 lumen flood pattern back-up LED's, modified BeeRadd under-hood lighting with two KC Cyclones; KB Voodoo cargo management system and standard rails, AllPro hi-lift jack mount, 48" hi-lift, RCI Metalworks aluminum front skid, Flyzeye 3VP-RS in glovebox and console, AFE CAI, Coupe fuse box cover, battery hold-down bracket and CAI air-box cover, Wurton pod led's installed as bed lights on Lowbrow Customs motorcycle fork brake line aluminum brackets, Pop-n-Lock PL5400, Extang Solidfold 2.0, Rechelon Retro's, Moromoto LED fogs, URD Y-pipe, Walbro 255lph fuel pump, Speedhut AFR and Boost gauges, Cravenspeed gauge holder, CMC by Tandem Automotive, 70mm throttle body, CSF radiator, Doug Thorley shorties, Vibrant 7101 cats, SOS Offroad front and rear bumpers, Smoothflow 2.5" SC pulley, Steeda SC belt tensioner, roostfactor belt wrap kit, switch Pro 9100 in custom Tandem Automotive holder, WAT trans valvebody, FIC 650cc injectors, HP Tuner.

@loginfailed knows the exact process. It's in this thread, but I can't remember how far back.
Norton Senior Member

Joined:

Mar 10, 2011

Member:

#52729

Messages:

4,379

Gender:

Male

First Name:

Steve

Colorado Springs, CO

Vehicle:

2013 Access Cab 4x4 V6 6MT, TRD OR & Tow Packages

Magnuson S/C w/12TRDTacoma's Qwikchange Hub & 2.5" RIP-Modded Pulley, Roostfactor's Pulley Wrap Mod; FPR Mod; JustDSM Tune via HPT MPVI2; mightytacoman Intercooler Tank; aFe POWER Magnum FLOW Pro DRY S Air Filter; OME Suspension Lift (885 Coils, Dakar Leafs, NitroCharger Sports); TRD Quickshifter w/TRD 6-Spd Knob; TRD Exhaust; NSB-AGM27F Battery w/HKB Adjustable Voltage Booster & Coupe's TRD Battery Hold Down; Goodridge SS Brake Lines; Trident904's MT ADM; Cooper Discoverer A/T3s on FJ SE Anthracite Rims; N-Fab 6-Step Nerf Bars; BPF TRD Skid & Cooling Panel; jsi's Locker Anytime, Up2NoGood's 2Lo Module; ramonortiz55's Always on Power Outlet Relay, ND4's Fog Light Anytime, & Crom's Speed Bleeder Mods; crashnburn80's Ultimate Headlight & Fog Light Upgrades; ThreatLevelMidnight's Wireless Charger; 4Runner 4X4 & FJ Fog Light Switches; redtaco2007-inspired LED License Plate Lights; mattgecko's Underhood Lighting; AudioControl LC2i LOC, JL Audio XD200/2v2 Amp, Focal PS165V1 Spkrs, Sound Ordnance B-8PTD Sub, Hushmat & Noico Sound Insulation; loginfailed-inspired Speedhut Boost & AFR Gauges in a Lotek Pillar Pod; Ltd Auto-Dim/Compass/Temp/Backup Camera/Homelink mirror on ImMrYo's Mirror Lift Bracket; Husky Floor Liners; UltraGauge EM; mesojdm's Ultimate LED Dome & Map Lights & GASSHOLE; Redline Tuning QuickLIFT Elite; Mobtown Offroad Locking Bed Storage Doors; Toyota Bed Mat; Cali Raised Led Bed Stiffeners; Pop & Lock Power Tailgate Lock w/TacomaTruckParts Support Bracket; ARE Z-Series Cap, SolarGard Tint; BlendMounted & MirrorTapped Uniden R3; CravenSpeed Stubby Antenna; Amsoil Lubricants; Adam's Detailing Supplies

Try a different dealership. The local one here flashed mine and a friend's following S/C install.
BassAckwards Well-Known Member

Joined:

May 3, 2016

Member:

#186002

Messages:

25,940

Gender:

Male

First Name:

Robert

Vehicle:

2013 6spd AWD Supercharged

Sure thing, glad it worked out for you
snowsk8air2 how hard can it be?

Joined:

Sep 16, 2011

Member:

#63607

Messages:

8,800

Gender:

Male

First Name:

Ryan

Flagstaff, AZ

Vehicle:

Supercharged TX Pro

2011 S/C and basic mods

Isn't that what the sc is for? I'm working on letting her breathe a little with a y-pipe coming and then deciding on headers.
BassAckwards Well-Known Member

Joined:

May 3, 2016

Member:

#186002

Messages:

25,940

Gender:

Male

First Name:

Robert

Vehicle:

2013 6spd AWD Supercharged
Try this procedure:
1. Disconnect battery
2. Swap new ECU into truck
3. Paperclip across pins 4 & 13 of 16-pin DLC3 (AKA: OBD2) connector
4. Reconnect battery
5. Hook up battery charger
6. Turn on ignition
7. Wait 30 minutes (use a timer, has to be at least 30 minutes)
8. Turn off ignition
9. Remove jumper from DLC3 connector
10. Try to start the truck
If it starts you're done.
I've done this as well. Straight out of Dwayne's build thread
BassAckwards Well-Known Member

Joined:

May 3, 2016

Member:

#186002

Messages:

25,940

Gender:

Male

First Name:

Robert

Vehicle:

2013 6spd AWD Supercharged

I sent my ECU off and had it reflashed by a member that was willing to help me. After i got it back, i had to reset the immobilizer in my truck to get it to start. Thats the procedure i posted up above. I've done this 4-5 times now without any issues
